Xct100 China Made Official 100 Ton Mobile Chinese Truck Crane

Operating Weight : 16t

Length-Base Boom : 10.4m

Length-Full-Extend Boom+Jib : 40.8m

Overall Dimensions(Lxwxh) : 122500X2820X3550

Theoretical Gradeability : 40%

Length-Full-Extend Boom : 20m

Transport Package : Roro or Bulk Shipment

Condition : Used

Maximum Lifting Height : >40m

Maximum Lifting Weight : >16t

Shaft Number : 4

Crane Jib : Four-Arm

Type : Folding

Customization : Available | Customized Request

Contact Now

Product Description

Company Info.

Customer Question & Answer

Ask something for more details

(0)

Basic Info.

Operating Weight

16t

Length-Base Boom

10.4m

Length-Full-Extend Boom+Jib

40.8m

Overall Dimensions(Lxwxh)

122500X2820X3550

Theoretical Gradeability

40%

Length-Full-Extend Boom

20m

Transport Package

Roro or Bulk Shipment

Product Description

XCT100 China Made Official 100 Ton Mobile Chinese Truck Crane

I. Feature
QY40K truck crane adopts full luxury cab with large view and new orthodrome streamline operating cab, which is good looking. Adopt five-segment oval rope retractable boom with double-cylinder and two-segment jib, greatly improving the working scope of the machine. The design of the streamline boom head is in keeping with the style of the machine. The boom and jib adopt new connection method, which is convenient to dismantle and install. It is equipped with the high-power environment protection engine, improving the chassis power and the trafficability.
II. Parameter

Classificatory	Item	Unit	Parameter
Engine	Model			D6114
Outline dimension	Overall length		mm	11990
	Overall width		mm	2500
	Overall height		mm	3350
	Wheel base	Axle 1, Axle 2	mm	4025
	Wheel base	Axle 2, Axle 3	mm	1350
Mass	Total mass in travel state		kg	22900
		Axle 1	kg	5240
	Axle load	Axle 2	kg	17660
Travel performance	Travel speed	Max. travel speed	km/h	70
	Travel speed	Min. stable travel speed	km/h	4
	Turning diameter	Min. turning diameter	m	20
	Turning diameter	Min. turning diameter at boom tip	m	23
	Min. ground clearance		mm	270
	Approach angle		(°)	21
	Departure angle		(°)	10
	Braking distance (at 30km/h with full load)		m	9.5
	Max. grade-ability		%	24
	Fuel consumption for 100km		L	35
Power	Engine rated output		kW/(r/min)	158/2200
	Engine rated torque		N.m/ (r/min)	790/1400
	Engine rated speed		r/min	2200
