Add to Compareshareliebherr Used Germany Truck Crane Ltm1170 Japanese 200ton Secondhand Crane

Operating Weight : 16t

Length-Base Boom : 10.4m

Length-Full-Extend Boom+Jib : 40.8m

Overall Dimensions(Lxwxh) : 122500X2820X3550

Theoretical Gradeability : 40%

Length-Full-Extend Boom : 20m

Transport Package : Roro or Bulk Shipment

Trademark : xcm

Condition : Used

Maximum Lifting Height : >40m

Maximum Lifting Weight : >16t

Shaft Number : 4

Crane Jib : Four-Arm

Type : Folding

Customization : Available | Customized Request

Contact Now

Product Description

Company Info.

Customer Question & Answer

Ask something for more details

(0)

Basic Info.

Operating Weight

16t

Length-Base Boom

10.4m

Length-Full-Extend Boom+Jib

40.8m

Overall Dimensions(Lxwxh)

122500X2820X3550

Theoretical Gradeability

40%

Length-Full-Extend Boom

20m

Transport Package

Roro or Bulk Shipment

Trademark

xcm

Product Description

Add to CompareShareliebherr used germany truck crane ltm1170 Japanese 200ton secondhand crane

I. Feature
More excellent performance
• The optimizing layout of the machine makes the stress of the main bearing carriers more reasonable, and the lifting performance is higher than the products with the same tonnage.
• Apply the mature jib technique which integrates plug-in boom head, embedded boom block, and special telescoping mechanism, which makes the jib more stable and reliable.
• Optimize the stress design. Adopt the box-type outriggers which have larger span, stronger rigidity, and better stability.
More reliable quality
• Adopt the classic K series jib telescoping technique, working safer and more reliable.
• Make the most complete safety device system in the industry, ensuring the lifting safer and more reliable.
• The comprehensively upgraded brake system adopts double circuit air pressure design. Multiple systems ensure the brake safety of the truck during travel.
• The new power steering mechanism adopts hydraulic power design, which makes the steering light, flexible, and precise, and ensures the safety of the truck.
• The intensity and rigidity of the rotary table and frame structure with high rigidity are completely coordinated.
• The perfect integration of the design and structure realizes the automation of welding, which is more reliable.
Easier to operate
• The high efficient and energy efficient load sensing hydraulic system is sensitive to operate and precise to control, having good slight mobility.
• Optimize the control levers, which is easier to operate.
• The cab adopts orthodrome front windscreen, having wider operating views.
Easier to maintain
• The optimizing design of the pipeline traces makes the layout more scientific and reasonable, greatly reducing the dismantling and installing time of the pipelines and the maintenance expense.
• Completely upgrade the electrical system. Adopt anti-creep connector clips, greatly prolonging the service life of the parts.
• Adopt K series rope anti-disorder technique, improving the lifting efficiency, reducing the labor intensity, and prolonging the service life of the steel rope.
• The telescoping steel wire rope oriented and protective device avoids the steel wire rope out of the track and broken.
• Fully covered walking plate supplies a platform for the maintenance, and effectively protects the parts of the machine.
More energy-efficient and environmental friendly
• Adopt double industrial automation control engine, featuring strong power and energy efficiency.
• Under the economical mode, it can meet the engine power requirement of the normal lifting work. Under the high power mode, it can meet the requirement of the high challenge and high efficient lifting work.
• Adopt the high power radiator, avoiding the system from bad cooling, solving the problem of oil overheating, and prolonging the service life of the hydraulic oil.
• Adopt the advanced matching technique, which makes the design more scientific. It can reduce the consumption of the mechanism, prolong the service life of the machine, and has high residual value.

II. Parameter

Dimension	Unit	QY12B.5
Overall length	mm	10200
Overall width	mm	2500
Overall height	mm	3200
Weight
Total weight in travel	kg	16000
Front axle load	kg	6000
Rear axle load	kg	10000
Power
Engine model		6C215,WD415.21,SC8DK230Q3
Engine rated power	kW/(r/min)	158/2200,155/2200,170/2200 790/1400,820/1400,830/1400
Engine rated torque	N.m/(r/min)	158/2200,155/2200,170/2200 790/1400,820/1400,830/1400
Travel
Max. travel speed	km/h	68,75
Min. turning diameter	mm	18000
Min. ground clearance	mm	260
Approach angle	°	21
Departure angle	°	10
Max. grade ability	%	≥26,≥28
Fuel consumption for 100km	L	30, 40
Main performance
Max. rated total lifting capacity	t	12
Min. rated working radius	m	3
Turning radius at turntable tail	m	2.6
Max. lifting torque	kN.m	428
Base boom	m	9.3
Fully extended boom	m	23
Fully extended boom+jib	m	29.4
Longitudinal outrigger span	m	4.1
Lateral outrigger span	m	4.9
Working speed
Boom luffing time	s	50
Boom full extension time	s	75
Max. swing speed	r/min	2.6
Main winch full load/no load (single rope)	m/min	110

III. PACKING
